产品特点:
1. 采用双驱闭环的系统构架,配备进口开放式数控系统,在高速运动条件下保证加工精度,生产效率高。
2. 标配500W光纤激光器,选配300W光纤激光器,运行和维护成本低。
3. 采用开放式结构,接近性好,方便上下料操作,抽屉式收料装置,让收料更方便。
4. 针对高速运动要求,设计和制造加强型焊接床身,两次时效处理,确保床体长期运行的精度和稳定性。
5. 标配三气源双压气路控制系统(高压空气、氮气、氧气),满足客户对各种材料的加工需求,操作简便,成本更低。
6. 优化的光学镜片,特殊设计的喷嘴和传感技术,使切割更流畅,更稳定。
技术参数
激光器类型 Laser type |
光纤激光器(可选300W) Fiber Laser |
激光功率(标配/选配) Laser Power |
500/300 |
激光头 Laser head |
Laser mech |
加工幅面 Working area |
1500*3000mm可定制 Can be customized |
工作台结构 Work table structure |
固定式工作台 Fixed work table |
控制系统 Control system |
PMAC伺服全闭环控制 PMAC servo loop control |
定位精度(毫米) Position accuracy (mm) |
0.05 |
驱动方式 Drive mode |
齿轮齿条/丝杠 Rack and pinion/screw |
空程度/加工速度(米/分) travel speed / processing speed (m/min) |
48/24 |
冷却系统 Cooling system |
双温双控冷水机 Dual temperature control chiller |
防护系统 Protecting system |
开放式 Open type |
软件支持格式 Software supported formats |
PLT ,DXF |
电源要求 Power requirements |
380V |
总功率(千瓦) Gross power |
7.5/6-12KW |
占地面积 Floor area |
5.6*3.2m |
其它标配功能 Other standared function |
金属排版软件、三气源双压气路、随动调焦、手柄等 Metal typesetting software, three dual-pressure gas line gas source, follow-up focus,handle,etc. |
