Goliath plasma flame cutting machine SAM-LM40120B
- Brand: sinosam
- Type: SAM-LM40120B
- Price: $ 13516.3611 RMB
- Promotion: $ 13215.3286 RMB ( 0 Customers Bought)
Product features:
1. The frame is made of thick steel plate welding, whole annealing treatment, high precision, small inertia, XYZ axis precision machining, prevent deformation.2. The drive for precision rack structure and special reducer, cable made by Germany imported materials.Ensure accuracy of operation.
3. The drive system adopts the chip control, servo drive, Japan panasonic motor, servo or optional inovance precision stepper driver and ac power supply, large torque, high speed smoothly.
4. The controller with high precision, conversion in both Chinese and English.A high precision automatic raised.
5. Optional models: A, 40120:4 m * 12 m (6 m, 8 m, 10 m)
technical parameters
|
Model |
SAM-LM40120B |
|
|
Cutting method |
Plasma |
Flame |
|
Cutting size |
3200*10000mm |
|
|
Machine size |
4300*12000mm |
|
|
Lifting travel |
≤170mm |
|
|
Max travel speed and cutting speed |
10000mm/min 0-15000mm/min |
|
|
Running accuracy |
≤0.005mm |
≤0.1mm |
|
Height control |
Are pressure auto THC |
Lifting body |
|
Cutting thickness |
Less than 20mm is the best |
6-200mm |
|
Cutting gas |
Air |
Oxygen+ethyne(propane) |
|
Gas pressure |
0.4-0.8Mpa |
|
|
Servo motor |
Dual drive |
|
|
Janpan Panasonic Swevo MotorInvance |
||
|
X,Y axis |
High Quality Rack & Pinon and Taiwan linear rail |
|
|
Auto ignition |
AR235 |
|
|
Power |
220V/380V 50HZ(we suggest 63A、120A、160A、200A，etc) |
|
|
Number of cutting torch/nozzle |
One set of plasma cutting torch/flame cutting torch,10pcs nozzle |
|
|
Support software |
Starcam, FASTCAM |
|
